Cat C1.7

Industrial Diesel Engines - Highly Regulated

About the Cat C1.7



The new electronic Cat® C1.7 Industrial Diesel Engines, with common rail fuel system, deliver impressive performance throughout a wide speed range with exceptional power density. Ultracompact package size and extensive options make them ideal for agriculture, aerial lifts, compressors, construction, general industrial, irrigation equipment, material handling, mobile earthmoving equipment, mobile light towers, turf and landscaping, underground mining equipment, and welders.

Specifications

Power Rating
Minimum Power 29 bkW
Maximum Power 29 bkW
Rated Speed 2800 rpm
Emission Standards
Emissions U.S. EPA Tier 4 Final, Japan 2014 (Tier 4 Final)
General
Engine Configuration In-Line 3, 4-Stroke-Cycle Diesel
Bore 84 mm (3.3 in)
Stroke 90 mm (3.5 in)
Displacement 1.7L (103.7 in³)
Aspiration Turbocharged (T)
Compression Ratio 18:1
Combustion System Direct Injection
Rotation from Flywheel End Counterclockwise
Cooling System - Capacity 2.8L (2.96 qt)
Lube System - Refill 3.6L (3.8 qt)
Engine Dimensions - Approximate
Height 736 mm (28.9 in)
Length 640 mm (25.2 in)
Weight - Net Dry - Basic Operating Engine Without Optional Attachments 190 kg (419 lbs)
Width 545 mm (21.4 in)
Aftertreatment Dimensions - Approximate
Diameter 155 mm (6.1 in)
Length 408.4 mm (16.07 in)
Weight 5.8 kg (12.79 lb)

Features

Reliable, Quiet and Durable Power

Reliable, Quiet and Durable Power
World-class manufacturing capability and processes coupled with proven core engine designs assure reliability, quiet operation, and many hours of productive life.

High Performance

High Performance
Substantial torque rise delivers impressive performance throughout a wide speed range while maintaining low operating costs.

Fuel Efficiency

Fuel Efficiency
Fuel consumption optimized to match operating cycles of a wide range of equipment and applications while maintaining low operating costs.

Broad Application Range

Broad Application Range
Industry leading range of factory configurable ratings and options for agricultural, material handling, construction, mining, aircraft ground support, and other industrial applications.

Package Size

Package Size
Ultra-compact package size ensures ease of installation as well as exceptional power density.

World-class Product Support Offered Through Global Cat Dealer Network

World-class Product Support Offered Through Global Cat Dealer Network
  • Scheduled maintenance, including SOSSM sample
  • Customer Support Agreements (CSA)
  • Caterpillar Extended Service Coverage (ESC)
  • Superior dealer service network
  • Extended dealer service network through the Cat Industrial Service Distributor (ISD) program

Tier 4 Final Aftertreatment Features

Tier 4 Final Aftertreatment Features
Regeneration Free. The Diesel Oxidation Catalyst (DOC) technology provides customers with an aftertreatment solution that is as compact as possible. The aftertreatment is regeneration-free, providing a seamless operation throughout the work cycle. Mounting. Mounted on-engine, as standard. This will provide the simplest installation and the lowest total cost for the equipment manufacturer. An off-engine option will be offered for some equipment.
