Cat C9.3 Marine Generator Set

Marine Generator Sets

Request quotation

About the Cat C9.3 Marine Generator Set



C9.3 ACERT genset packages with heat exchanger or keel cooling are available with60 Hertz ratings of 250 ekW (313 kVA) and 300 ekW (375 kVA) and 50 Hz ratings of 200 ekW (250 kVA) and 250 ekW (313 kVA). Radiator cooled gen sets are with 60 Hz ratings of 224 ekW (280 kVA) and 274 ekW (343 kVA) and 50 Hz ratings of 185 ekW (231 kVA) and 235 ekW (294 kVA). The C9.3 propulsion, auxiliary, and generator set engines have a common rail fuel system for optimal combustion and lower emissions. Cooling system options for the propulsion and auxiliary engines include heat exchanger with sea water aftercooling, and keel with combined circuit or separate circuit aftercooling. The genset packages are available with heat exchanger, keel, or radiator cooling. These products are EPA Tier 3 and IMO II certified. In addition the propulsionengine ratings are EU Stage IIIA certified and auxiliary and gen sets are also CCNR Stage II certified.

Specifications

Generator Set Specifications
Minimum Rating 185R ekW (231 kVA) at 50hz, 224R ekW (280 kVA) at 60hz
Maximum Rating 250R ekW (313 kVA) at 50hz, 300 ekW (375 kVA) at 60hz
Frequency 50 Hertz & 60 Hertz
Speed 1500 rpm @ 50Hz & 1800 rpm @ 60Hz
Engine Specifications
Aspiration Turbocharged Aftercooled
Bore 4.13 in
Stroke 5.31 in
Fuel System Common Rail
Engine Model C9.3
Generator Set Configurations
Emissions/Fuel Strategy EPA Tier 3, IMO II, EU IW
Generator Set Dimensions
Height 56.5 in
Length - Engine 85.8 in
Weight - Approximate 5219 lb
Width - Engine 50.4 in
Generator Specifications
Excitation Permanent Magnet
Insulation Class H
Drip Proof IP23
Number of Leads 12-Lead 2 wires per lead
Voltage Regulator approx. 0.5%
