Cat XQP100

Mobile Generator Sets

Download specifications Request quotation
CM20170117-10605-20633
CM20170117-10605-23668

About the Cat XQP100



This XQP100 generator set will either meet EU Stage IIIA emission standards or provide low fuel consumption performance for customers in non-regulated territories. With a robust, rental or mobile-ready construction, the product line is designed to be easily transported around project sites safely and efficiently. Heavy-duty bases with integrated fork lift pockets allow the unit to be dragged and lifted with ease, while Clipsal or CEE socket options are available on select models to reduce installation time and provide trouble-free power distribution.

Specifications

Dimensions
Width 44.1 in
Height 72.7 in
Length 109.1 in
Weight 4469 lb
Fuel Consumption EU Stage IIIA
100% Load 50Hz 6.2 gal/hr
100% Load 60Hz 7.3 gal/hr
75% Load 50Hz 5.4 gal/hr
75% Load 60Hz 5.9 gal/hr
50% Load 50Hz 3.9 gal/hr
50% Load 60Hz 4.2 gal/hr
Fuel consumption Best Fuel Efficiency
100% Load 50Hz 6 gal/hr
100% Load 60Hz 7.1 gal/hr
75% Load 50Hz 4.5 gal/hr
75% Load 60Hz 5.3 gal/hr
50% Load 50Hz 3.1 gal/hr
50% Load 60Hz 3.7 gal/hr

Features

Rental ready

Rental ready
Robust, durable product with a range of rental ready features to meet job requirements and applications.

Fuel/Emissions Strategy

Fuel/Emissions Strategy
Emissions Equivalent to EU Stage IIIA and Best Fuel Efficiency.

Cat C4.4 Diesel Engine

Cat C4.4 Diesel Engine
Industry proven reliability.

Cat LC3100 Generator

Cat LC3100 Generator
Integrated voltage regular for fast response in demanding applications.

Robust Galvanised Enclosure

Robust Galvanised Enclosure
Inhibits corrosion in service. Prevents water ingress, provides security and sound attenuation.

Sound Isolated Operator Panel

Sound Isolated Operator Panel
Improved operator comfort.

Cat Connect

Cat Connect
Remote monitoring for fleet management and asset tracking.

Factory Designed, Built and Tested

Factory Designed, Built and Tested
Supported by an industry leading global dealer network.

500 hr Oil Change Intervals

500 hr Oil Change Intervals
Reducing operating costs and producing less waste.

Additional Options Available

Additional Options Available
Synchronising controls. Distribution sockets. Extended Service interval kits.
