Cat D6T Track-Type Tractor

Medium Dozers

About the Cat D6T Track-Type Tractor

The new D6T dozer makes high efficiency dozing easy. A smooth-shifting, fully automatic four-speed Cat® transmission continuously optimizes the power train for the application. You save fuel and operator effort, without sacrificing durability, power or productivity. Work smarter too, with a full range of Cat Connect GRADE technology features to fit your job site needs.

Specifications

Engine

Flywheel Power	215 HP
Displacement	567 in³
Net Power - 2,200 rpm - ISO 9249/SAE J1349	215 HP
Net Power - 2,200 rpm - ISO 9249/SAE J1349 (DIN)	218 HP
Net Power - Maximum - ISO 9249/SAE J1349 at 1,200 rpm	245 HP
Net Power - Maximum - ISO 9249/SAE J1349 (DIN) at 1,200 rpm	248 HP

Service Refill Capacities

Fuel Tank	97.2 gal (US)
DEF Tank	4.5 gal (US)

Weights

Operating Weight

47139 lb

Operating Weights

LGP S	51366 lb
XL Fine Grading	49935 lb
XL Narrow	49780 lb
XL SU	47139 lb
XL VPAT	53043 lb
XW SU	48910 lb
XW VPAT	54046 lb
XW VPAT - With Foldable Blade	58852 lb
LGP VPAT	54527 lb
LGP VPAT - With Foldable Blade	59333 lb

Blades - Capacity

6 S - LGP	4.96 yd³
6 SU - XL	7.26 yd³
6 SU - XL Narrow*	6.47 yd³
6 SU - XW	7.38 yd³
6 VPAT - LGP	6.57 yd³
6 VPAT - XL	6.07 yd³
6 VPAT - XW	6.57 yd³
6 VPAT - XW Foldable	7.83 yd³
6 VPAT - LGP Foldable	7.83 yd³

Blades - Width

6 S - LGP	13.33 ft
6 SU - XL	10.7 ft
6 SU - XL Narrow*	9.81 ft
6 SU - XW	11.69 ft
6 VPAT - LGP	13.65 ft
6 VPAT - LGP Foldable	12.65 ft
6 VPAT - XL	12.75 ft
6 VPAT - XW	13.65 ft
6 VPAT - XW Foldable	12.65 ft

Dimensions - LGP

Ground Clearance	16 in
Ground Pressure (ISO 16754)(3)	5.1 psi
Length - Basic Tractor(2)	14.48 ft
Length - Track on Ground	10.65 ft
Machine Height - To Product Link Antenna(1)	10.84 ft
Width - Tractor - Without Trunnions - Standard Track	10.5 ft

Dimensions - LGP VPAT

Ground Clearance	16 in
Ground Pressure (ISO 16754)(3)	6.3 psi
Length - Basic Tractor(2)	16.41 ft
Length - Track on Ground	10.65 ft
Machine Height - To Product Link Antenna(1)	10.84 ft
Width - Tractor - Without Trunnions - Standard Track	10.31 ft

Dimensions - LGP VPAT Foldable

Ground Clearance	16 in
Ground Pressure (ISO 16754)(3)	6.8 psi
Length - Basic Tractor(2)	16.41 ft
Length - Track on Ground	10.65 ft
Machine Height - To Product Link Antenna(1)	10.84 ft
Width - Tractor - Without Trunnions - Standard Track	10.31 ft

Dimensions - XL

Ground Clearance	14.8 in
Ground Pressure (ISO 16754)(3)	8.7 psi
Length - Basic Tractor(2)	13.81 ft
Length - Track on Ground	9.23 ft
Machine Height - To Product Link Antenna(1)	10.67 ft
Width - Tractor - Without Trunnions - Standard Track	8.01 ft

Dimensions - XL Fine Grading

Ground Clearance	14.8 in
Ground Pressure (ISO 16754)(3)	9.4 psi
Length - Basic Tractor(2)	13.81 ft
Length - Track on Ground	9.23 ft
Machine Height - To Product Link Antenna(1)	10.67 ft
Width - Tractor - Without Trunnions - Standard Track	8.01 ft

Dimensions - XL Narrow

Ground Clearance	14.8 in
Ground Pressure (ISO 16754)(3)	9.4 psi
Length - Basic Tractor(2)	13.81 ft
Length - Track on Ground	9.23 ft
Machine Height - To Product Link Antenna(1)	10.67 ft
Width - Tractor - Without Trunnions - Standard Track	8.01 ft

Dimensions - XL VPAT

Ground Clearance	14.8 in
Ground Pressure (ISO 16754)(3)	9.8 psi
Length - Basic Tractor(2)	16.06 ft
Length - Track on Ground	9.23 ft
Machine Height - To Product Link Antenna(1)	10.67 ft
Width - Tractor - Without Trunnions - Standard Track	8.91 ft

Dimensions - XW

Ground Clearance	14.8 in
Ground Pressure (ISO 16754)(3)	6.6 psi
Length - Basic Tractor(2)	13.81 ft
Length - Track on Ground	9.23 ft
Machine Height - To Product Link Antenna(1)	10.67 ft
Width - Tractor - Without Trunnions - Standard Track	9.16 ft

Dimensions - XW VPAT

Ground Clearance	16 in
Ground Pressure (ISO 16754)(3)	6.9 psi
Length - Basic Tractor(2)	16.41 ft
Length - Track on Ground	10.65 ft
Machine Height - To Product Link Antenna(1)	10.84 ft
Width - Tractor - Without Trunnions - Standard Track	9.83 ft

Dimensions - XW VPAT Foldable

Ground Clearance	16 in
Ground Pressure (ISO 16754)(3)	7.5 psi
Length - Basic Tractor(2)	16.41 ft
Length - Track on Ground	10.65 ft
Machine Height - To Product Link Antenna(1)	10.84 ft
Width - Tractor - Without Trunnions - Standard Track	9.83 ft

Features

Performance

New, fully automatic four-speed lock-up clutch transmission continuously optimizes gear and engine speed for the application without added operator input.
Added gear between first and second, and seamless lock-up clutch engagement, for exceptionally smooth shifting.
Maintains power to the ground through load changes for an aggressive feel in the dirt.
Up to 2.5 percent more productive – move more material per hour.*
Faster implement response*, especially with GRADE technologies.
Versatility – pushing power you want for heavy dozing and the fine control you need for finish grading – all in one easy-to-transport machine.

*Compared to previous model.

Efficiency

Full-time Auto Shift for significantly better fuel efficiency with less operator effort – without sacrificing performance.
Up to 20 percent more fuel efficient* – as much as 30 percent better in lighter load finish grading applications.
Sustainable: fuel savings reduces CO2 production by an average of approximately 16.6 metric tons per year.

*Compared to previous model.

Cat Connect Technology

Automatically maintain established blade position with Cat GRADE with Slope Assist (Standard). Finish jobs faster, with better surface quality and significantly less operator effort. No additional hardware required.
Whether production dozing or finish grading, take on 3D design plans more efficiently with Cat GRADE with 3D (Optional). Factory integrated grade control system features cab roof-mounted GNSS antennas to eliminate blade masts and cables. Includes AutoCarry™ to further boost productivity.
Versatile, scalable Cat AccuGrade™ (Optional) is a dealer-installed grade control system. Choice of Laser, Global Navigation Satellite System (GNSS) or Universal Total Station (UTS) so you get the right level of accuracy to match your job requirements.
Factory equip your dozer for easy installation of an AccuGrade system with the AccuGrade Ready Option (ARO) (Optional).
Manage your fleet more effectively and profitably with Product Link™/VisionLink® remote monitoring.

Cat Connect-technologie voor de bulldozer D6T

Ease of Operation

Change ground speeds easily – in large (half gear) or small (one-tenth gear) increments – with detented thumb roller.
New Liquid Crystal Display (LCD) places machine data, settings menus, grade control data and more conveniently in front of the operator.
Display enables coded start and operator profiles.
Improved blade feedback with updated implement joystick.
More ground clearance and better penetration with new high-lift, multi-shank ripper.
Easier transport with available narrow blade/push arms on D6T XL, or foldable blade on XW/LGP VPAT tractors.
